Analysis of Dynamic Message Passing Programs

Well-structured transition systems (WSTS)

A well-structured transition system is a transition system 〈S, →, ≤〉  where

• ≤ is a well-quasi-ordering (wqo), i.e. well-founded + no infinite antichain
• compatibility of ≤ w.r.t. → (also called monotonicity)

Compatibility in general	Compatibility in our example

The property we check also needs to respect the ordering (upward-closed).

Some references: [Abdulla et al. 96, Finkel and Schnoebelen 01]

Depth-bounded systems (DBS)

The states are labelled directed graphs (in families) of bounded tree-depth. (the direction of the edges is irrelevant for the depth.) More concretely, this corresponds to the family of graph where the longest acyclic path is bounded. Here is an example state for our running example:

The transitions are graph rewriting rules:

The ordering is subgraph isomorphism. This is a wqo only on families of graphs where the tree-depth is bounded. Also we assume that there is a finite number of labels.

The covering problem: can the system reach a configuration which is greater (or equal) to the target.

• motivation + running example
• preliminaries
• part 1: domains of limits
• part 2: ideal abstraction
• part 3: analysis on top of the covering set
• part 4: implementation and experiments
• conclusion

Toward a forward analysis of DBS:
domain of limits

Approach to the covering problem: saturation-based forward exploration

The goal is to compute the covering set $C$, i.e. the downward-closure of the reachable states. $C$ is an inductive invariant ($\mathrm{post}\left(C\right)\subseteq C$ and $\mathrm{init}\subseteq C$ ).

Problem: how do we represent $C$ ? (it can be infinite)

Representing the covering set

The covering set has special properties: wqo space, downward-closed.
It can be represented by a finite union of ideal.

Since [Karp and Miller 69] these kind of sets have been represented using some notion of limits. However, general formalizations of the concept came much later:

• adequate domain of limits (axiomatisation) [Geeraerts et al. 06]
• noetherian/sober space (topology) [Goubault-Larrecq 07]
• ideal completion (order theory) [Finkel and Goubault-Larrecq 09]

Limit configurations

We represent limits by nested graphs.
The subgraphs marked by dashed-blue boxes represent an unbounded number of copies of that subgraph.
We can obtain normal graphs from nested graphs by unfolding.

Results [Wies, Zufferey, and Henzinger 10]

Theorem: Limit configurations are the denotation of the ideals of depth-bounded systems.

ingredient of the proof:

• '!' in π-calculus,
• tree closure of graph,
• theorems about tree embeddings,
• hedge automaton for unranked trees,
• etc.

• motivation + running example
• preliminaries
• part 1: domains of limits
• part 2: ideal abstraction
• part 3: analysis on top of the covering set
• part 4: implementation and experiments
• conclusion

Bridging the gap between theory and practice:
ideal abstraction

In [Zufferey, Wies, and Henzinger 12], we define an abstract interpretation framework [Cousot and Cousot 77] for the analysis of WSTS.
Try to capture the essence of acceleration with a set-widening operator.
Instantiate the framework for:

• Petri nets + monotonic extensions
• Lossy channel systems
• Depth-bounded systems

Covering set for our running example

• motivation + running example
• preliminaries
• part 1: domains of limits
• part 2: ideal abstraction
• part 3: analysis on top of the covering set
• part 4: implementation and experiments
• conclusion

Further analysis on top of the covering set

Basic idea: cover + one step

Structural counter abstraction

The automaton above is a very coarse overapproximation of the original system. To recover some precision we add counters that keep track of how many copies of a nested node there are.

Results: In [Bansal, Koskinen, Wies, and Zufferey 13] we apply the structural counters abstraction to prove termination of DBS.

Using the same idea we are working on DPI.

• motivation + running example
• preliminaries
• part 1: domains of limits
• part 2: ideal abstraction
• part 3: analysis on top of the covering set
• part 4: implementation and experiments
• conclusion

Implementation: Picasso

Related Work

• π-calculus [Milner et al 92]
• WSTS/Petri nets to analyse concurrent program (counter abstraction): too many to cite ...
• Abstract interpretation for WSTS [Ganty et al 06]
• Termination of lock-free algorithms [Gotsman et al 09]
• Other group working on DBS: analysis or Erlang program [D'Osualdo et al 12]
• etc.

Conclusion

• Developed a framework for the analysis of DBS:
  • Limits for DBS
  • Sound and terminating analysis
  • Structural counter abstraction
• Applicable to:
• distributed systems (client-server)
• shared memory (flat collection)
• Safety (covering) and liveness (termination)
• Implementation in Picasso
